LISSOM - Flame Retardant Low Smoke

Lissom FRLS cables have higher oxygen and temperature indices and lower smoke density rating as well as acid gas generation. They are made of special insulation material that retards flame propagation and generates low smoke under fire condition.

90 mtrs. coils packed in protective cartons. Project coils of 180 mtrs also available.

FRLS cable is ideal for use in conduit and for fixed protected installation particularly suitable for wiring in fire and explosion prone areas, chemical factories, densely wired areas, public buildings, schools, hospitals, commercial complexes, theatres, etc.


Technical Table "LISSOM" FRLS as per IS : 694/1990 (650/1100 V)

Conductor Area Sq. mm Insulation Thickness mm Number Nominal Dia. Of Stands* Approx Overall Dia. mm DC Conductor Resistance ohm/km at 20° C (max) Current Rating Amps.
Casing Concealed
1.0 0.6 14/0.3 2.8 18.1 14 12
1.5 0.7 22/0.3 3.1 12.1 18 14
2.5 0.8 36/0.3 3.7 7.41 24 18
4.0 0.8 56/0.3 4.1 4.95 32 24
6.0 0.8 84/0.3 4.8 3.3 42 32

Properties

Test Specification Specified Values
Critical oxygen Index ASTM-D 2863 > 29%
Temperature Index ASTM-D 2863 > 250° C
Acid Gas Generation IEC 60754-1 < 20%
Smoke Density Rating ASTM-D 2843 < 60%

*The number and diameter of conductor strands are for reference only.

"LISSOM" Cables will not responsible for any damages arising out of incorrect application of its products.

The Above data is Indicative and may be revised without prior Information
