LISSOM - Round Flexible Multicore Cables
IN its continuous pursuit of empowering various industries with the safest wiring solutions, "LISSOM" has also developed products like Multi-core round flexible cables which are not only safe but perfect for industrial environment conditions and ideal for concealed wiring.
These cables are also manufactured from 99.97% pure bare copper conductors and insulated with a special grade PVC jacket to protect them against oil, grease, acid, various chemicals and abrasions.
Technical Table - "LISSOM" Round Flexible Multicore cables as per IS : 694/1990 (650/1100 V)
| Area in sq. mm | Construcation No./Dia | Con. Dia. In mm | Max. DC Resistance Ohm/Km | Insulation Thickness Nominal at 20° C | Core Dia mm | Sheath thickness in mm nominal | Overall Diameter in mm approx. | Current Rating Amp. | ||||
| 2 Core mm | 3 Core mm | 4 Core mm | 2 Core mm | 3 Core mm | 4 Core mm | |||||||
| 0.50 | 16/0.20 | 0.94 | 39.000 | 0.60 | 2.20 | 0.90 | 0.90 | 0.90 | 7.00 | 7.40 | 8.00 | 6 |
| 0.75 | 24/0.20 | 1.20 | 26.000 | 0.60 | 2.50 | 0.90 | 0.90 | 0.90 | 6.80 | 7.60 | 8.25 | 9 |
| 1.00 | 32/0.20 | 1.34 | 19.500 | 0.60 | 2.60 | 0.90 | 0.90 | 0.90 | 7.00 | 7.90 | 8.65 | 14 |
| 1.50 | 48/0.20 | 1.64 | 13.300 | 0.60 | 2.90 | 0.90 | 0.90 | 1.00 | 7.60 | 8.10 | 9.00 | 18 |
| 2.50 | 80/0.20 | 2.08 | 7.980 | 0.70 | 3.50 | 1.00 | 1.00 | 1.00 | 9.00 | 9.60 | 10.50 | 24 |
| 4.00 | 56/0.30 | 2.61 | 4.950 | 0.80 | 4.30 | 1.00 | 1.00 | 1.00 | 10.60 | 11.30 | 12.40 | 32 |
| 6.00 | 84/0.30 | 3.50 | 3.300 | 0.80 | 5.10 | 1.15 | 1.15 | 1.40 | 12.60 | 13.40 | 15.20 | 36 |
| 10.00 | 140/0.30 | 4.60 | 1.910 | 1.00 | 6.60 | 1.40 | 1.40 | 1.40 | 16.00 | 17.00 | 18.80 | 45 |
| 16.00 | 224/0.30 | 6.00 | 1.210 | 1.00 | 8.00 | 1.40 | 1.40 | 1.40 | 18.80 | 20.10 | 22.20 | 60 |
| 25.00 | 350/0.30 | 7.60 | 0.780 | 1.20 | 10.00 | 2.00 | 1.00 | 2.00 | 24.00 | 25.60 | 28.20 | 75 |
| 35.00 | 490/0.30 | 8.70 | 0.554 | 1.20 | 11.10 | 2.00 | 2.00 | 2.00 | 26.30 | 28.00 | 31.00 | 95 |
| 50.00 | 700/0.30 | 10.60 | 0.386 | 1.40 | 13.40 | 2.00 | 2.00 | 2.00 | 30.90 | 33.00 | 36.50 | 125 |
*The number and diameter of conductor strands are for reference only.
"LISSOM" Cables will not responsible for any damages arising out of incorrect application of its products.
The Above data is Indicative and may be revised without prior Information
