LISSOM - ZHFR - House ⁄ Building Wires
Lissom ZHFR cables possess some very important characteristics like Eco Friendly, Non Toxic, Fire Resistant, Lead Free, No Halogen, Non Carcinogenic and Anti Corrosiveness. These wires are used where safety is required the most like hospitals, theaters, hi-rise buildings, commercial complexes etc.
90 mtrs. coils packed in protective cartons. Project coils of 180 mtrs also available.
Technical Table "LISSOM" ZHFR as per IS : 694/1990 (650/1100 V)
Conductor Area Sq. mm | Insulation Thickness mm | Number Nominal Dia. Of Stands* | Approx Overall Dia. mm | DC Conductor Resistance ohm/km at 20° C (max) | Current Rating Amps. | |
Casing | Concealed | |||||
1.0 | 0.6 | 14/0.3 | 2.8 | 18.1 | 14 | 12 |
1.5 | 0.7 | 22/0.3 | 3.1 | 12.1 | 18 | 14 |
2.5 | 0.8 | 36/0.3 | 3.7 | 7.41 | 24 | 18 |
4.0 | 0.8 | 56/0.3 | 4.1 | 4.95 | 32 | 24 |
6.0 | 0.8 | 84/0.3 | 4.8 | 3.3 | 42 | 32 |
Properties
Test | Specification | Specified Values |
Critical oxygen Index | ASTM-D 2863 | > 29% |
Temperature Index | ASTM-D 2863 | > 250° C |
Acid Gas Generation | IEC 60754-1 | < 0.5% |
Smoke Density Rating | ASTM-D 2843 | < 20% |
*The number and diameter of conductor strands are for reference only.
"LISSOM" Cables will not responsible for any damages arising out of incorrect application of its products.
The Above data is Indicative and may be revised without prior Information
